2D finite element analysis are performed to get the accurate deflection.
#Plaxis 2d anchor software
The research has shown that the finite element results are higher than the experimental findings in loose sand. Coulomb model through finite element software (PLAXIS 7.2 software) and compared. Fine mesh used in PLAXIS for circular anchor plate in failure mechanism setting. In the Plaxis 2D FEA, horizontal interface elements were used along the. Numerical analysis using square anchor plates was conducted based on the hardening soil model (HSM). Meshes used in PLAXIS for circular anchor plate with embedment ratio L/D 5. CAPACITY ANALYSIS OF SUCTION ANCHORS IN CLAY BY 3DFINITE ELEMENT ANALYSISL.
Agreement between the uplift responses from the physical model tests and finite element modeling using PLAXIS 2D, based on 100 mm computed maximum displacements was excellent for square anchor plates. Validation of the analysis model was also carried out with 50 mm, 75 mm and 100 mm Length square plates in loose sand. The behavior of square anchor plates during uplift test was studied by experimental data and finite element analyses in loose sand. The uplift response of symmetrical square anchor plates has been evaluated in physical model tests and numerical simulations using Plaxis. A two dimensional finite element program PLAXIS 2D has been used to model a single frame of a berthing structure using the concept of plain strain condition.
